PRIZM Core Neo Board: Your Gateway to Seamless IoT Integration

PRIZM's Core Neo is a compact 40mm x 40mm IoT controller board designed for fast development and deployment of connected devices. It integrates an ESP32-S3 processor, 2.4GHz Wi-Fi and LTE Cat. 1 bis cellular connectivity, and a 2 x 20 pin expansion header, enhancing performance while keeping a small mechanical footprint.

Built around the dual-core ESP32-S3, it includes an onboard accelerometer and a real-time clock with backup battery, a Qwiic-compatible I2C connector, and USB-C power input. Applications are deployed and updated over the air through the PRIZM cloud.
